Commercial Garage Door Openers

Commercial Garage Door Openers

Whether You Need Trolley or Hoist Operators, We Offer Innovative Industry-Proven Solutions.

Jackshaft (J) Style Operator

Jackshaft (J) style commercial door operators are optimal for industrial applications. Doors used with this operator should be balanced with the ability to be manually lifted by hand in an emergency or power outage.

Connectivity:

  • MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone, tablet, or computer for greater peace of mind.

  • Alerts can be received as email or pop-up (push) notifications on a mobile device, ensuring the status of your commercial door.

  • MyQ Mobile App is a free download with no annual activation fee.

  • Requires 828LM MyQ Internet Gateway to connect to MyQ Smartphone App.

garage door repair lewisville tx garage 234

Performance:

  • Dual Voltage Connections increase flexibility by enabling the installer to select the required voltage within phase, to meet job-site requirements.
  • Single-Phase: 115V and 230V, 3-Phase: 208V, 230V and 460V, 575V is a discrete model without field-selectable voltage.
  • Control Function Selector Dial enables easy selection and programming of (7) wiring types, from constant pressure to close, to specialized Timer-to-Close functionality to meet end-user needs.
  • Continuous-duty high-starting Torque Motor performs in demanding industrial overhead door applications.
  • Motor Removable without Affecting Limit Switch Settings saves time and money for maintenance.
  • Adjustable Friction Clutch helps to protect the door and operator from damage should the door meet an obstruction.

  • Mid-Stop enables partial opening of the door to a preprogrammed position for energy savings, time savings, and convenience.

  • Maximum Run Timer reverses or stops door if closing time exceeds the expected time-frame to limit damage to door and operator.
  • Delay-On-Reverse Circuit prevents abrupt reversal of door, reducing wear on the door and operator system.
  • 3-Button Control Station with Maintenance Alert System (MAS) provides open/close/stop functions and notifications when routine maintenance is required.
  • Continuous-duty high-starting torque motor with instant reverse and overload protection. Available in 1/3, 1/2, 3/4, and 1 HP; single- or three-phase. The capacitor starts in a single phase. Removable without affecting limit switch settings.
  • Operators are factory preset to C2 wiring, providing momentary contact to open and stop, with constant contact to close.
  • 5V DC NEC Class 2.
  • First-stage heavy-duty 5L V-belt; second #41 chain; #48 (for 1/3 and 1/2HP) and #41 (for 3/4 and 1HP) output chain on trolley.
  • Industrial ball bearings on the output shaft, heavy-duty oil-filled bushings on reduction shafts.
  • Brake Standard on 3/4 and 1 HP operators, (optional on 1/2 HP, not available on 1/3 HP).

  • NEMA 1 type electrical box, heavy-duty 11-gauge steel frame with durable powder coat finish, all reduction sprockets drilled and pinned to shafts.

  • #48 on 1/3 and 1/2 HP. #41 on 3/4 and 1HP.
  • Two-year warranty.

Safety and Security:

UL 325 requires all commercial door operators to be either under constant pressure to close or be equipped with a primary external monitored entrapment protection device.

Security+ 2.0™ safeguards your facility – with every click, a new code is sent to the commercial door operator so the door opens only for you.

Timer-To-Close conveniently and confidently closes the commercial door automatically after a predetermined amount of time has elapsed for added security and peace of mind.

Emergency Disconnect disconnects the operator from the door for manual lifting in an emergency.

Hoist (H) Style Operator

Hoist (H) style commercial door operators are optimal for industrial applications. H-style operators include a floor-level chain hoist to ease manual operation in an emergency or power outage.

Connectivity:

  • MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone, tablet, or computer for greater peace of mind.
  • Alerts can be received as email or pop-up (push) notifications on a mobile device, ensuring the status of your commercial door.

  • MyQ Mobile App is a free download with no annual activation fee.

  • Requires 828LM MyQ Internet Gateway to connect to MyQ Smartphone App.

Performance:

  • Dual Voltage Connections increase flexibility by enabling the installer to select the required voltage within phase, to meet job-site requirements.
  • Single-Phase: 115V and 230V, 3-Phase: 208V, 230V and 460V, 575V is a discrete model without field-selectable voltage.
  • Control Function Selector Dial enables easy selection and programming of (7) wiring types, from constant pressure to close, to specialized Timer-to-Close functionality to meet end-user needs.
  • Continuous-duty high-starting Torque Motor performs in demanding industrial overhead door applications.
  • Motor Removable without Affecting Limit Switch Settings saves time and money for maintenance.
  • Adjustable Friction Clutch helps to protect the door and operator from damage should the door meet an obstruction.
  • Mid-Stop enables partial opening of the door to a preprogrammed position for energy savings, time savings, and convenience.
  • Maximum Run Timer reverses or stops door if closing time exceeds the expected time-frame to limit damage to door and operator.

  • Delay-On-Reverse Circuit prevents abrupt reversal of door, reducing wear on the door and operator system.

  • 3-Button Control Station with Maintenance Alert System (MAS) provides open/close/stop functions and notifications when routine maintenance is required.

  • Continuous-duty high-starting torque motor with instant reverse and overload protection. Available in 1/3, 1/2, 3/4, and 1 HP; single- or three-phase. The capacitor starts in a single phase. Removable without affecting limit switch settings.

  • Operators are factory preset to C2 wiring, providing momentary contact to open and stop, with constant contact to close.

  • 5V DC NEC Class 2.
  • First-stage heavy-duty 5L V-belt; second-third-fourth stages #48 chain; #50 output sprocket chain.
  • Industrial ball bearings on 1″ output shaft, heavy-duty oil-filled bushings on reduction shafts.
  • Brake standard on 3/4 and 1 HP operators. (optional on 1/2 HP; not available on 1/3 HP).
  • NEMA 1 type electrical box, heavy-duty 11-gauge steel frame with durable powder coat finish, all reduction sprockets drilled and pinned to shafts.

  • Two-year warranty.

Safety and Security:

UL 325 requires all commercial door operators to be either under constant pressure to close or be equipped with a primary external monitored entrapment protection device.

Security+ 2.0™ safeguards your facility – with every click, a new code is sent to the commercial door operator so the door opens only for you.

Timer-To-Close conveniently and confidently closes the commercial door automatically after a predetermined amount of time has elapsed for added security and peace of mind.

Floor Level Chain Hoist with Electrical Interlock provides easy disconnect and manual operation in an emergency.

LiftMaster Operators Come Standard with These Advanced Features:

MyQ Technology:

Enables Secure Monitoring and control of the operator with a smartphone, tablet, or computer.

Provides revolutionary technology only found in LiftMaster Commercial Door Operators.

Each Internet Gateway device (828LM) can manage up to 16 operators or devices. Multiple Internet gateways may be installed to accommodate additional commercial devices.

Built-in Security+ 2.0® Radio Receiver:

Provides industry-leading technology only found in LiftMaster Commercial Door Operators.

Increased security – With every click, a new code is sent to the Commercial Door Operator ensuring the door opens only for the individual pressing the remote.

Enhanced radio communicates with tri-band frequency to improve range and reduce interference – assuring the door opens, stops, and closes conveniently and reliably every time.

Timer-to-Close:

Provides functionality for the operator to automatically close the door as soon as the vehicles are clear, eliminating the potential for theft and damage, and keeping your business secure while you’re away.

Maintenance Alert System:

  • Provides a reminder to contact your LiftMaster Dealer for routine maintenance.

  • The system can be set to alert upon a calendar date or after a selected number of operator cycles.
